iBasso DC04 PRO DAC Amplifier with 3.5mm 4.4mm Plug for iPhone Android Smartphone Lightning Type-C
iBasso DC04 PRO DAC Amplifier with 3.5mm 4.4mm Plug for iPhone Android Smartphone Lightning Type-C
Brand: iBasso
Low stock: 1 left
Couldn't load pickup availability
iBasso DC04 Pro - Upgrade Your Audio Experience
Meet the all-new iBasso DC04 Pro, an upgrade on the highly-acclaimed DC04 Portable USB DAC/AMP. With a premium dual DAC arrangement housing two CS43131 flagship-grade DAC chips and a powerful amp section consisting of dual RT6863 chips, the DC04 Pro delivers a powerful and clean sound experience that brings your high-resolution audio requirements to life. The primary upgrade on the DC04 Pro over the OG DC04 includes a single-ended 3.5mm headphone output along with the balanced 4.4mm one. Upgrade your portable audio setup with the all-new iBasso DC04 Pro today!
Flagship-Grade Dual DAC Chipset
The iBasso DC04 Pro features a premium Dual DAC Chipset housing two CS43131 high-performance 32-Bit DAC chips from Cirrus Logic. They offer best-in-class performance with ultra-low distortion and high signal-to-noise ratio performance, producing a clean output with high dynamic range.
High-Resolution Audio Signal Decoding
The iBasso DC04 Pro decodes high-resolution audio signals with support for all leading high-resolution PCM and DSD audio signals, supporting up to 32-Bit/384kHz PCM signals and up to DSD256 signals natively.
Dual Headphone Output Ports (3.5mm + 4.4mm)
The device provides a single-ended 3.5mm output and a 4.4mm balanced headphone output option, making it compatible with most IEMs and headphones straight out of the box.
Powerful Amplification Circuit
The DC04 Pro utilizes dual RT6863 amp chips that produce powerful signal amplification while maintaining low THD+N distortion and high SNR performance.
Exclusively Premium Finish With All-Aluminum Build
The device has an exclusive unibody build with an all-aluminum chassis and tempered glass panel for a solid structure, offering an elegant finish that looks exquisite.
Clean Performance With Ultra-Low-Noise LDO
The ultra-low noise LDO supply circuit ensures clean power is delivered to different components on the audio circuitry, enhancing overall performance.
FPGA + KDS Crystal Oscillator
The in-house developed FPGA algorithm supported by a KDS crystal oscillator helps in delivering clear and accurate high-resolution audio signal decoding performance.
Features
- High-performance Dual CS43131 DAC chips
- Dual Independent RT6863 Amp Chips
- FPGA + KDS Femtosecond Oscillator
- Elegant Unibody design
- iBasso Mobile App support
- Fully Balanced 4.4mm Headphone Output
- Single-Ended 3.5mm Headphone Output
- Decodes PCM Up To 32Bit/384kHz
- DSD256 Support
- CNC Machined Aluminum Alloy Build With Tempered Glass Panels
- Lower-Power Consumption
- Physical Volume Keys
- Ultra-Low Noise LDO
- Detachable Cable Design
Technical Specifications
4.4mm Output Specifications:
- THD+N: 0.00013% (300Ω)
- Output Level: 3.0Vrms (32Ω), 4.0Vrms (300Ω)
- SNR: 131dB
- DNR: 128dB
- Frequency Response: 20Hz-40kHz
- Output Impedance: <0.4Ω
3.5mm Output Specifications:
- THD+N: 0.00018% (300Ω)
- Output Level: 2.0Vrms (32Ω), 2.0Vrms (300Ω)
- SNR: 127dB
- DNR: 126dB
- Frequency Response: 20Hz-40kHz
- Output Impedance:<0.2Ω
